The VN2C 6×6 wheeled mine-resistant armoured vehicle is the latest model developed by NORINCO. It newly adopts a more powerful engine developing 300kW for higher tactical mobility, and rear door opens downwards as a ramp for easily getting on and off the vehicle.
The VN2C 6×6 wheeled mine-resistant armoured vehicle adopts unique general layout and modular chassis structure to improve ballistic protection and explosion-proof capability. The unique design reduces damage against crew and vehicle greatly during explosion of mines and LEDs, or attack of small arms, RPG rockets.
Features
Adopts middle-left-positioned power pack, V-shaped chassis body, external-positioned axle, monocoque body without wheel cover to improve anti-explosion capability greatly
Protection capability reaches NATO STANAG 4569 III
Integral power-transmission module that can be lifted as a whole assembly
Rear door opens downwards as ramp for passengers’ quick ascending and descending
Comfortable driving & smooth traveling thanks to high-power engine
Modular design to ensure good reliability & maintainability
Equipped with NBC, smoke grenade launcher, fire extinguishing, etc
Specifications: |
|
|---|---|
| Property | Value |
| Weight (kg) | 19000 |
| Number of wheels | 6 |
| Number of drive wheels | 6 |
| Crew | 3 |
| Troops | 8 |
| Max. road speed (km/h) | 100 |
| Max. road range (km) | 800 |
| Engine power output (h.p.) | 400 |
| Main weapon caliber (mm) | 12.7 |
| Auxiliary gun calibre (mm) | 7.62 |
| Ammunition of the main gun | 500 |
| Ammunition of the auxiliary gun | 1000 |
| Length (mm) | 7000 |
| Width (mm) | 3000 |
| Height (mm) | 2250 |
| Ground clearance (mm) | 410 |
| Trench (mm) | 1200 |
| Vertical obstacle (mm) | 550 |
| Max. water speed (km/h) | 8 |
