We customize UAV (including target) rocket boosters according to different needs of customers。
Firefox UAV boost engine series：
Product description
It has the characteristics of short working time and large instantaneous thrust. The diameter is generally less than 250mm. It includes a variety of booster engines with different diameters and different total impulses. The total impulse range is 4kN·s～55kN·s, which can meet the assistance of various types of UAVs. Push launch requirements, product reliability as high as 99%, can meet the storage and use requirements of 10 years.
Technical characteristics
Thrust line lateral shift <0.4mm;
Optimized design of combustion surface to reduce thrust fluctuation;
Solve the influence of thrust deflection and fluctuations on launch attitude;
Reduce the difficulty of UAV system design and use;
Optimized design of combustion surface to reduce thrust fluctuation;
Solve the influence of thrust deflection and fluctuations on launch attitude;
Reduce the difficulty of UAV system design and use;
Product parameter
| Model | 365 | 220 | 200A | 200 | 122B |
| Average thrust | 56.1kN | 21.2kN | 13.4kN | 17kN | 10.5kN |
| Working time | 2.9s | 2.5s | 3s | 2s | 2s |
| Diameter | 363mm | 220mm | 200mm | 200mm | 122mm |
| Total impulse | 153kN•s | 53kN·s | 40kN·s | 34kN·s | 21kN·s |
