Reconnaissance and Strike Multirotor Drone Harwar Tomahawk

Main features:

1. Large load (load 25KG)
2. Long endurance (60 minutes)
3. Full perception (720° omnidirectional obstacle avoidance, distance, vibration, temperature, wind speed, weather perception)
4. All-weather (wind resistance level 7, rain proof, dustproof, adapt to -40-85° environment)
5, Multi-task (single sortie at the same time to perform multi-task, monitoring and fighting as one)
6. Multiple applications (36 times zoom reconnaissance, security control, smoke bombs, detonation bombs, tear grenades and other grenade launch, missile launch, air capture, air Shouting, air lighting, air explosive disposal)

Specifications：

Model		Tomahawk H16-V6		Tomahawk H16-V6-5G		Tomahawk H16-V12		Tomahawk H16-V12-5G
Dimensions		1530mm×1750mm×830mm
Distance		1650mm
Endurance		≤60min		≤60min		≤60min		≤60min
Maximum Load		≤15kg		≤15 kg		≤25 kg		≤25 kg
Flight radius		≤15 km		5G signal coverage		≤15 km		5G signal coverage
Working temperature		-40°~+85°		-40°~+65°		-40°~+85°		-40°~+65°
Disassembling time		≤2min		≤2min		≤2min		≤2min
Power battery		28000mAh		28000mAh		28000mAh		28000mAh
Flight speed		≤18m/s		≤15m/s		≤18m/s		≤15m/s
Altitude		≤5834m		≤5500m		≤5834m		≤5500m
wind resistance		Level 7		Level 7		Level 7		Level 7
Sand dust		IP65		IP65		IP65		IP65
Rain level		Moderate rain		Moderate rain		Moderate rain		Moderate rain
Standard  function	Intelligent flight	Ground imitation flight, pointing flight, pointing task, breakpoint continued flight, AB point one-key take-off and landing, one-key return, route planning, multi-task management
	Safety protection	Anti-electromagnetic interference、Triple redundancy protection、Low electricity return、Low voltage return、Propeller broke protect
	Omnidirectional obstacle avoidance	720° obstacle avoidance, sensing range ≤200 meters
	Satellite positioning	Beidou, GPS, GLONASS, RTK Samsung seven band
	Positioning accuracy	Horizontal: ±0.02m  Vertical: ±0.05 m
	Body material	Carbon fiber composite material + aviation aluminum
Aircraft color		Police aviation white	Blue and white		Carbon black		Police aviation black		Red

Tomahawk drone foot footstool installation mode

Attack function module

YT – SGG high altitude Forward launch module	YT-95LC high altitude long-range transmitting module
YT – SGL high altitude down launch module	YT-SGLII high altitude down launch module II

Certification

The Tomahawk H16 UAV has passed ISO9001, ISO14001, QC80000 and other quality system certification, FCC, CE, Ministry of Public Security testing certification, National Optoelectronic Information Product Quality Supervision and Inspection Center certification, CEPRI China Electric Power Research Institute testing certification.

Tomahawk drone pictures

Tomahawk drone H16-V6
